Denso

Voltage Set Point 14v A Circuit Replaces: Toyota 27700–23010 (stamped 2861, 3040, 3041)

Voltage Set Point 14.0 A Circuit Replaces: (stamped 041005, PCM01) Note: Regulation voltage controlled by vehicle PCM.

Voltage Set Point 14.5V A Circuit Note: Standard lamp function – no output.

Voltage Set Point 14.4V A Circuit Notes - D-terminal has no function.,Active lamp function - with output.

Voltage Set Point 14.5V A Circuit S-IG-L Terminals, 14.5 Vset, 5 sec. LRC

Voltage Set Point 14.5 A Circuit

Voltage Set Point 13.8 A Circuit Low Side Drive Regulator

Voltage Set Point 14.9 A Circuit Plug Not Used Self Exciting

Voltage Set Point 14.5V A Circuit

Voltage Set Point 14.35V B Circuit

Voltage Set Point 14.2V B Circuit

Voltage Set Point 14.3V A Circuit

Voltage Set Point 28.4 A Circuit

Voltage Set Point 14.5 A Circuit Active lamp function - with output.,Without LRC

Voltage Set Point 14.4 A Circuit D+, PHIN-L Terminal, 14.4 Vset

Voltage Set Point 14.5 B Circuit Low Side Drive Regulator

Voltage Set Point 14.35 A Circuit Heavy Duty ASVR Design Welded construction - no solder joints for hi-temperature reliability & increased field life Short-circuit protection

Voltage Set Point 14.03 A Circuit Low Side Drive Regulator RC or Stator Activated Black Plug Type

Voltage Set Point 28.3 A-Circuit, Low Side Drive Ignition Activated

Voltage Set Point 14.0 A Circuit Active lamp function - with output

Voltage Set Point 14.4 A Circuit Active lamp function - with output

Voltage Set Point 14.3v A Circuit

Voltage Set Point 14.8V A Circuit

Voltage Set Point 14.1 B Circuit Ignition activated Notes - Standard lamp function - no output.,Without LRC.,Must have 1K Resistor between the FR and IG
