Denso

Voltage Set Point 14.0V A Circuit PCM Controlled Regulation Voltage

Voltage Set Point 14.0V B Circuit PCM controlled regulation voltage Brown Plug Type

Voltage Set Point 14.5V A Circuit IG-L Terminals Active lamp function - with output

Voltage Set Point 14.6V A Circuit S-IG-L Terminals

Voltage Set Point 14.4V A Circuit

Voltage Set Point 14.6 B Circuit Replaces: (stamped 3660)

Voltage Set Point 14.1V B Circuit Full range LRC Multi–step TempCo (unless in RLO mode)

Voltage Set Point 15.3V A Circuit With Soft Start

Voltage Set Point 14.4V A Circuit With Soft Start

Voltage Set Point 13.5V B Circuit PCM controlled regulation voltage (stamped 3430, 3640)

Voltage Set Point 14.2V B Circuit

Voltage Set Point 14.1V B Circuit (stamped GS2M3010, GS2M3040, GS3M3390)

Voltage Set Point 14.8 A Circuit

Voltage Set Point 14.5 A Circuit (M = Frequency) Terminals,

Voltage Set Point 14.5 A Circuit Standard lamp function - no output.

Voltage Set Point 14.5 A Circuit wo/ indicator light latching feature

Voltage Set Point 14.6 A Circuit S-IG-L Terminals, 14.6 Vset, w/ LRC

Voltage Set Point 14.4 A Circuit

Voltage Set Point 14.4 A Circuit

Voltage Set Point 14.4 A Circuit Replaces Denso 126000–1960 w/ 14.6 Vset.

Voltage Set Point 14.4 B Circuit

Voltage Set Point 14.5 A Circuit

Voltage Set Point 14.5 A Circuit

Voltage Set Point 14.5 A Circuit

Voltage Set Point 14v A Circuit Replaces: Toyota 27700–23010 (stamped 2861, 3040, 3041)

Voltage Set Point 14.0 A Circuit Replaces: (stamped 041005, PCM01) Note: Regulation voltage controlled by vehicle PCM.

Voltage Set Point 14.5V A Circuit Note: Standard lamp function – no output.

Voltage Set Point 14.4V A Circuit Notes - D-terminal has no function.,Active lamp function - with output.

Voltage Set Point 14.5V A Circuit S-IG-L Terminals, 14.5 Vset, 5 sec. LRC

Voltage Set Point 14.5 A Circuit

Voltage Set Point 13.8 A Circuit Low Side Drive Regulator

Voltage Set Point 14.9 A Circuit Plug Not Used Self Exciting

Voltage Set Point 14.5V A Circuit

Voltage Set Point 14.35V B Circuit

Voltage Set Point 14.2V B Circuit

Voltage Set Point 14.3V A Circuit

Voltage Set Point 28.4 A Circuit

Voltage Set Point 14.5 A Circuit Active lamp function - with output.,Without LRC

Voltage Set Point 14.4 A Circuit D+, PHIN-L Terminal, 14.4 Vset

Voltage Set Point 14.5 B Circuit Low Side Drive Regulator

Voltage Set Point 14.35 A Circuit Heavy Duty ASVR Design Welded construction - no solder joints for hi-temperature reliability & increased field life Short-circuit protection

Voltage Set Point 14.03 A Circuit Low Side Drive Regulator RC or Stator Activated Black Plug Type

Voltage Set Point 28.3 A-Circuit, Low Side Drive Ignition Activated

Voltage Set Point 14.0 A Circuit Active lamp function - with output

Voltage Set Point 14.4 A Circuit Active lamp function - with output

Voltage Set Point 14.3v A Circuit

Voltage Set Point 14.8V A Circuit

Voltage Set Point 14.1 B Circuit Ignition activated Notes - Standard lamp function - no output.,Without LRC.,Must have 1K Resistor between the FR and IG

Voltage Set Point 14.5 A Circuit

Voltage Set Point 14.5 A Circuit

Voltage Set Point B Circuit Stator Activated Field Rating 5 Amps Voltage Set point and Regulation Mode is controlled by Vehicle

Voltage Set Point 14.50 B Circuit Field Rating 5 Amps Computer "C" Function Standard Lamp Function - No Output IGN Activated

12 Volt, B-Circuit, Single Pin LIN Terminal Transpo Denso Honda

Voltage Set Point 14.45 B Circuit High Side Drive Regulator S-L-AM on OE alternator label. AS-IG-LI terminal functions. Not a PCM regulator

Voltage Set Point 28.4 A Circuit Active lamp function - with output

Voltage Set Point 14.V A Circuit With Soft Start
